7" IPS TFT LCD module, 1024×600, RGB (JM-PT034)
- Model
- JM-PT034
- Size
- 7"
- Brand
- Junxian Display
- Place of origin
- Shenzhen, China
- Sample MOQ
- 5 pcs
- Production MOQ
- 100 pcs (standard) / 1,000 pcs (fully custom)
- Lead time
- 10-20 days
- Payment
- T/T, L/C, PayPal
- Trade terms
- EXW, FOB Shenzhen, CIF
Specifications
Model JM-PT034, built in our Shenzhen plant - 300 cd/m² brightness, -10°C to +70°C operating range, ST7735S driver IC. Sample MOQ is 5 pcs, production MOQ 100 pcs, and lead time 10-20 days once the specification is frozen.
| Model number | JM-PT034 |
|---|---|
| Screen size | 7" |
| Resolution | 1024×600 |
| Display type | IPS |
| Interface | RGB Vertical Stripe |
| Brightness | 300 cd/m² |
| Colours | 262K |
| Touch panel | CTP Touch Screen |
| Driver IC | ST7735S |
| Driving voltage | 3.3V |
| Backlight | LED White Light |
| Backlight lifetime | 40,000 Hours |
| Outline dimension | 164.00x97.00x2.6mm |
| Active area | 154.21X85.92mm |
| Operating temperature | -10°C to +70°C |
| Storage temperature | -20°C to +70°C |
| Compliance | REACH & RoHS Compliant |
Typical values at 25 °C. Tolerances, pin assignment and timing are in the datasheet — ask for it before locking your PCB layout.
Price depends on quantity, touch option and packaging. Send the quantity and we quote the same working day where possible.
Mechanical drawing
Outline, active area position, FPC route and pin pitch. Dimensions in millimetres. Check this against your enclosure opening before you commit the mechanical design — it is free to change here and expensive to change after tooling.
Drawing carried over from our previous catalogue; some annotations are in Chinese. Ask us for the current 2D drawing (DWG or PDF) and we will send it with the datasheet.
Product description
Product Features and Advantages
(1) Vivid IPS Visuals with Wide Angles
The 7-inch IPS panel (1024×RGB×600 WXGA resolution, 16.7 million colors, 800:1 contrast) delivers sharp, true-to-life imagery. Full IPS viewing angles ensure consistent color accuracy and clarity for multi-user or shared-view scenarios (e.g., outdoor signage viewed from various directions).
(2) Outdoor-Ready Custom Brightness
With 300 cd/m² typical luminance (customizable for higher brightness), the display eliminates glare and maintains readability under strong sunlight—suited to outdoor signage, automotive dashboards, or rugged handheld devices.
(3)Rugged & Reliable Performance
Engineered for extreme environments: operates in -10°C~70°C (stores in -20°C~70°C) and features anti-static protection. Ideal for industrial, automotive, or outdoor applications where stability in harsh conditions is critical.
(4) Compact & Easy Integration
Slim dimensions (164.00×99.00×4.10 mm) fit space-constrained designs. The TTL interface ensures seamless compatibility with standard digital systems, reducing integration complexity for developers.
(5) Certified Quality Excellence
Delivering consistent quality, long lifespan, and trustworthiness for B2B buyers.
Detail photos
What this specification means in practice
IPS glass keeps colour and contrast stable from any angle, which matters when the operator does not look at the panel straight on - wall-mounted HMIs, instruments read from above, shared displays.
300 cd/m² suits indoor instruments and panel HMIs. If the device will sit outdoors or under direct light, ask us for the high-brightness version of this glass instead.
The parallel RGB interface needs a host with an LCD controller and around 20-28 I/O lines. It gives full frame-rate colour without a frame buffer IC, which is why it is standard on industrial ARM boards.
Operating range -10°C to +70°C is a commercial specification. For unheated outdoor use ask for the wide-temperature version of this size.
The capacitive touch panel is bonded in-house. Tell us whether the device is used with gloves or in wet conditions - it changes the sensor stack and the controller tuning, and it is far cheaper to decide before tooling than after.
Ordering and customisation
This model ships as a bare module by default. We commonly modify the FPC length and connector, change the backlight current, add a capacitive or resistive touch panel, or bond cover glass with your printing. Tell us the enclosure opening and the mounting method and we will confirm what can stay standard and what needs tooling.
Typical applications
Industrial Automation & HMI
Machine panels and PLC front ends, where the module sits behind a cut-out in a metal enclosure and has to survive years of vibration.
Instrumentation & Metering
Bench and field instruments that show waveforms, curves or multi-line readings that a segment display cannot express.
Smart Home & Appliances
Control panels for appliances and thermostats, usually behind printed cover glass.
Handheld Terminals & POS
Portable terminals where the module size sets the whole enclosure dimension.
How a customised order runs
Send the requirement
Size, resolution, interface, brightness, operating temperature, touch or no touch, and the annual quantity. A photo or drawing of the enclosure opening helps more than a long description.
We confirm feasibility and quote
You get a specific model number or a modification plan, with tooling cost and lead time stated separately from the unit price. Usually within one working day.
Sample and approval
Samples in 10-15 days from stock glass; custom glass or a new FPC adds tooling time. You approve dimensions, display quality and interface timing before mass production starts.
Production and shipment
10-20 days after specification freeze. Anti-static bag + foam tray + export carton, shipped DHL / FedEx / UPS express or by your forwarder. We keep the approved sample as the reference for every repeat order.
